Key Advantages
Non-Wetting Precision
- Generates humidity levels ranging from 1% to 99% without wetting
- Rapidly diffuses for uniform humidity that never fluctuates (±1%)
- Utilizes decorrelation, the most energy efficient way to generate droplets
- Prevents all rust via 100% water use efficiency and non-wetting humidity
Ease of Use
- Requires no droplet screens, drain pans, or evaporation chambers
- Modular system that can merge multiple units to fulfill dynamic needs
- Easy to install and adjust to the application or size specifications
- USA-made with high-quality materials for durable turnkey solutions
- No moving parts, no clogging, no frequent maintenance
Applications
- Create precise, non-wetting environments for high quality control
- Disinfect spaces by reducing dust and pathogens and eradicating mold
- Regulate temperature with efficient double cooling technology
- Eliminate static and electrostatic discharge to reduce workplace hazard
Included system components
CPLC Controller
- The CPLC Controller is the intelligent controller behind all ES100 humidification systems, using advanced proprietary algorithms for ‘set and forget’ accuracy.
Pipe & Fittings Kit
- We provide all the PE pipes and fittings necessary for easy and safe installation. Simply cut and push the pipes for adjustable, hassle-free connectivity.
S Series – Relative Humidity Sensors
- S Series sensors ensure humidity accuracy within a range of 1% to 2% (depending on sensor model) so the CPLC Controller can trigger an accurate response, even when temperatures vary.
PB Control Center
- The PB Control Center, a plug-and-play system, efficiently maintains humidity levels with long-lasting valve control, requiring easy replacement approximately every 30 years.
Models
To increase capacity and scale operations,
add modular units to any model
TS100
Our TS100 humidification model features the following:
- Capacity: 0 – 3GPH / 0 – 25.02 Lbs / 0 – 11 Lph
- Operating Temperatures: (45° – 180°F)
- Water pressure requirement: 10 psi
- Compressed Air Requirement: 4 CFM at 100 psi
- Energy Consumption: 0.4 kW at maximum capacity. (Based on average compressed air use)
ES100-H
Our ES100-H model provides these features:
- Capacity: 0 – 3GPH / 0 – 25.02 Lbs / 0 – 11 Lph
- Operating Temperatures: (26-180°F)
- Compressed Air requirement: 4 CFM @100 psi- 150 psi
- Water pressure requirement: 10 psi
- Energy Consumption: 0.4 kW at maximum capacity (Based on average compressed air use)
OPTIONAL SYSTEM
COMPONENTS
Smart Fog offers additional components to help you manage humidification processes effectively and efficiently. Our professionals can walk you through the options and recommend system enhancements aligned with your needs.
Integration Package
Enable remote system control, convenient data collection and easy communication with controllers. Our Integration Package offers compatibility with most information systems, like Modbus and BACnet.
INJ-1 Automatic Injection System”
Streamline your humidification management with sensors. Our INJ-1 uses automation to transfer precise amounts of water-dissolving materials into the system for sanitization, disinfection or preservation.
ZeroTDS Filter System
Produce up to 1,000 gallons of purified DI water daily with a ZeroTDS Filter System. Our built-in sensors indicate when it’s time for filter changes.
Benefits of In-Duct Humidifiers
Investing in humidification systems offers many benefits, including:
Maintained Product Quality
Humidity precision allows you to manage product consistency and customer satisfaction.
Better Energy Efficiency
State-of-the-art, energy-efficient equipment allows you to save on your utility bills over time.
Reduced Allergens
Humidifiers add moisture to the air for increased comfort while reducing dust, pollen, bacteria and viruses.
Reduced Hazards
Added moisture makes the air more conductive and able to absorb excess charges, reducing the likelihood of static shocks within buildings.
Our In-Duct Humidification Systems
Get ready to transform your environment with Smart Fog. Our duct-mounted humidifiers generate humidity levels between 1% and 99% with non-wetting precision. Each model uses decorrelation, the most energy-efficient way to generate droplets.
Without evaporation chambers, drain pans or droplet screens, our models offer the ultimate convenience. You can easily install and adjust the modular systems to reduce allergens and bacteria, regulate temperatures and eliminate static.
Our systems include:
- Intelligent controllers: Our ES100 humidification systems feature CPLC Controllers with advanced proprietary algorithms for “set and forget” accuracy.
- Pipe and fittings kits: We provide pipes you can cut and adjust as needed for simple, stress-free installations.
- Humidity sensors: Our S Series sensors range from 1% to 2% humidity accuracy, even when temperatures vary.
- PB control centers: We provide efficient, plug-and-play systems with valve controls that last approximately 30 years.
